Manawa Flex Ureteral Access Sheath

Specifications
Design
Resources

Product Details:

Flexible Ureteral Access Sheath
Designed for easier, less tramatic scope manipulation during ureteroscopy. The flexible ureteral access sheath is designed to protect the ureter during repeated instruments exchanges during ureteroscopy.

Kink Resistant Sheath
Sheath is reinforced with a stainless steel coil designed to provide stability and strength during placement.

Ease of Insertion
Hydrophilic coated sheath, designed for lubricity during sheath placement.
Dual tapered dilator tip designed for atraumatic insertion.

User Friendly
Radiopaque marker band on the sheath confirms placement of the sheath tip during fluoroscopy.
Innovative hub design providing a secure latching mechanism.

Ordering Information:

Order Number	Internal Diameter French Size	External Diameter French Size	Length
UAS-0309520S	9.5Fr	11.5Fr	20cm
UAS-0309528S	9.5Fr	11.5Fr	28cm
UAS-0309535S	9.5Fr	11.5Fr	35cm
UAS-0309545S	9.5Fr	11.5Fr	45cm
UAS-0310720S	10.7Fr	12.7Fr	20cm
UAS-0310728S	10.7Fr	12.7Fr	28cm
UAS-0310735S	10.7Fr	12.7Fr	35cm
UAS-0310745S	10.7Fr	12.7Fr	45cm
UAS-0312020S	12.0Fr	14.0Fr	20cm
UAS-0312028S	12.0Fr	14.0Fr	28cm
UAS-0312035S	12.0Fr	14.0Fr	35cm
UAS-0312045S	12.0Fr	14.0Fr	45cm

	The sheath and dilator materials choices are using the softest polymers on the market, designed to provided the most flexible sheath without compromising access to the most challenging anatomy
	The sheath material is reinforced with a stainless steel coil, designed to provide stability and strength.
	The secure double latch mechanism allows for one-handed latch disengagement without rotational alignment.
	Manawa Flex Access Sheath is compatible with 0.038” guidewires.
	The sheath material is reinforced with a stainless steel coil design to maximize the pushability and column strength even in the most challenging tortuous urinary tract.
	Proprietary hydrophilic coating is applied on sheath outside diameter and dilator tip allowing ease of insertion.
	The low profile sheath allows ease of insertion and facilitates placement even in the most challenging tortuous anatomies. The outside diameter of the sheath is only 2Fr bigger than the dilator tubing across the entire range.

Image Library

Datasheet PDF

The flexible ureteral access sheath is intended to be used to provide ureteral dilatation with continuous working channel for the introduction of urological instruments such as ureteroscopes and for the injection of fluids into the urinary tract during ureteral access procedures. The Manawa Flex Ureteral Access Sheath is engineered with reinforced kink resistant stainless steel coil material and designed to provide best in class flexibility while maintaining its strength to reach the most difficult tortuous urinary district.
